Description
SOLD OUT!
Working Table Dimensions : 1200×730 mm
Working Height Of Spindle : 180 mm
Max. Diameter Of Linear Profiling Tool : 250 mm
Max. Diameter Of Tenoning Tool : 350 mm
Max. Diameter Of Moulding Tool : 160 mm
Spindle Moulder Stroke : 90 mm
Spindle Moulder Speed : 3000/4500/6000/7000/10000 RPM
Max. Dimensions Of Returning Tool Under The Table : 320×85 mm
Exhaust Hood On Fence, Diameter : 120 mm
Exhaust Hood Behind The Base, Diameter : 120 mm
Dimensions : 2600x1100x1730 mm
Standard Equipement
Manual tool-holder movement, complete with mechanical dagital readout of working height
Adjustable fence with wooden support tables
Microswitch on motor access door
Emergency pushbotton
Padlockable main switch
Overload switch protection
” ll ” version with 2 profiling extensions
Total length of table 2500 mm complete with front support bar for large workpieces
Emergency pushbotton
