Description
Working Table Dimensions : 1200×730 mm
Working Height Of Spindle : 170 mm
Max. Diameter Of Linear Profiling Tool : 250 mm
Max. Diameter Of Tenoning Tool : 350 mm
Max. Diameter Of Moulding Tool : 160 mm
Spindle Moulder Stroke : 90 mm
Spindle Moulder Speed : 3000/4500/6000/8000/10000 RPM
Max. Dimensions Of Returning Tool Under The Table : 320×85 mm
Exhaust Hood On Fence, Diameter : 120 mm
Exhaust Hood Behind The Base, Diameter : 120 mm
Spindle Moulder Shaft Diameter : 35 mm
Dimensions : 1200x800x1200 mm
Fixed shaft
With electrical protection
Carriage on fixed table for small tenoning operations
Locking by countersunk socket screw
Locking with slot
