Description
Max. Working Height Of Single Element Solid Wood : 170 mm
Min./Max. Working Height Of Assembled Frame : 740/1030 mm
Vertical Working Unit
Chisel Mortiser : Standard
Pneumatic Vertical Stroke : 150 mm
Longitudinal Stroke : 260 mm
Transversal Stroke : 70 mm
Mortiser Motor : 2.2 KW
Worktable
Dimensions : 140×470 mm
Inclination : 45°
Pneumatic Workpiece Locking : Standard
Installation
Max. Power Supply : 2.23 KW
Pneumatic Plant Working Pressure : 6 Bar
Upper Dust Extraction Outlet : 60 mm
Air Extraction Speed : 25-30 m/sec
Net Weight : 440 KG
Dimensions : 900x830x2000 mm
