الوصف
Dimension Axis X : 4700 mm
Dimension Axis Y : 1300 mm
Dimension Axis Z : 400 mm
Run C Axis : 640°
Run B Axis : 270°
Piece Passage : 200 mm
Milling Unit : 5 axes
Rotation Speed : 600 – 20000 RPM
Max Power : 11 KW / 15 HP / 15000 RPM
Drilling Unit : 12 spindles (7+5 verticals – 6 horizontals (4 ON X + 2 ON Y)
Motor Power : 2.2 KW
Tool holders : 24
Vacuum : 250 m³/h
Vector Speed X/Y: 97 m/min
Dimensions : 7200x3900x3500 mm
Electro-spindle with HSK F 63 connection.
